ASME B16.9 carbon steel elbow fittings are the most specified butt-weld pipe fittings in process piping. They are used to redirect flow, accommodate thermal expansion, and avoid unnecessary welds in long runs. Huaxia-Steel supplies long radius (LR) and short radius (SR) elbows in 45, 90, and 180 degree angles, made from seamless or welded carbon steel to ASME B16.9 and EN 10253.
Product Overview
Our elbows are produced by hot-pushing (mandrel) or cold-forming (segmented and welded) depending on size and grade. They can be matched to ASTM A106 Gr.B, API 5L Gr.B, ASTM A234 WPB, or EN 10253 pipe and supplied bare, sand-blasted, or primed.
Specifications
| Item | Details |
|---|---|
| Standard | ASME B16.9 / EN 10253-1 / GOST 17375 |
| Material grades | ASTM A234 WPB, A420 WPL6, EN P265GH, P355GH |
| Size range (NPS) | 1/2″ – 48″ |
| Wall thickness | SCH 10, SCH 20, STD, SCH 40, XS, SCH 80, XXS |
| Bend type | LR (1.5D), SR (1D) |
| Angle | 45, 90, 180 degrees; custom angles on request |
| Ends | Plain end, beveled to ASME B16.25 |
| Surface | Black, sand-blasted, primed, hot-dip galvanized |
Available Grades
- ASTM A234 WPB – matches ASTM A106 Gr.B pipe
- ASTM A234 WPC – higher strength, matches ASTM A106 Gr.C
- ASTM A420 WPL6 – low-temperature service to -46 degrees C
- EN P265GH – general European pressure grade
- EN P355GH – higher strength for elevated temperature
- ASME SA234 WP11 / WP22 – chrome-moly for high-temperature
Manufacturing Standards
- ASME B16.9 (factory-made wrought butt-welding fittings)
- ASME B16.25 (butt-welding ends)
- EN 10253-1 (wrought butt-welding fittings without specific inspection)
- EN 10253-2 (wrought butt-welding fittings with specific inspection)
- MSS SP-75 (high-strength fittings for low-temperature)
Applications
- Refinery and petrochemical process piping
- Boiler and steam distribution headers
- Power plant cooling water and auxiliary piping
- Ship and offshore module piping
- Compressor and pump suction and discharge lines
Quality Assurance
Each elbow is dimensionally checked against ASME B16.9 tolerances. Material certificates include chemistry, tensile, hardness, and, where specified, Charpy impact at low temperature. Surface and weld integrity are 100% inspected. PMI (positive material identification) is available for all carbon and alloy grades. Third-party inspection by SGS, BV, or TÜV can be coordinated.
Packing and Shipping
Elbows are packed in wooden crates or pallets, with each fitting wrapped in protective paper and the size, schedule, and grade marked on the outside. Small elbows are bundled together for shipment; large ones (>24 inch) are individually secured.
Why Buy Carbon Steel Elbows from Huaxia-Steel?
- Wide size range in stock and mill-order
- ASME, EN, and GOST standards covered
- Matched grades for ASTM A106, API 5L, and EN pipe
- Optional low-temperature and high-temperature alloys
- Mill-direct export pricing with one-stop documentation
Request a quote for ASME B16.9 carbon steel elbow pipe fittings. Provide the NPS, schedule, angle, radius type, grade, quantity, and destination, and our team will respond with a detailed offer.
