Carbon Steel Perforated Sheet — Factory Direct Supplier | Huaxia-Steel

Carbon steel perforated sheet is flat plate or coil punched with a regular pattern of holes for filtration, ventilation, screening, acoustic control, and architectural design. Huaxia-Steel produces perforated carbon steel in thicknesses from 0.3 mm to 12 mm, with round, square, slotted, hexagonal, and decorative hole patterns, in standard and custom pitches, to ISO 7805, ASTM E2740, and customer drawings.

Product Overview

Perforation is performed on CNC turret punch presses or rotary die machines, depending on thickness, pattern complexity, and volume. For thin gauges (0.3–2.0 mm), high-speed rotary perforation delivers clean burr-free holes at up to 200 strokes per minute. For thicker plates (3–12 mm), hydraulic punch presses with tool steel dies produce accurate holes with minimal taper. We supply sheets in standard sizes (1×2 m, 1.22×2.44 m, 1.5×3 m) or cut-to-size panels, and coils up to 1,500 mm wide for continuous roll-forming operations.

Specifications

Parameter	Details
Thickness	0.3 – 12.0 mm (tolerance per EN 10051 / ASTM A635)
Sheet size	1,000 × 2,000 mm; 1,220 × 2,440 mm; 1,500 × 3,000 mm; custom
Coil width	Up to 1,500 mm
Hole shape	Round, square, slotted, hexagonal, triangular, decorative
Hole diameter	0.5 mm – 50 mm
Pitch (center-to-center)	1.0 × D to 4.0 × D (staggered or straight rows)
Open area	10% – 70% depending on pattern
Materials	Q195, Q235, SPHC, S275, S355, DC01, A1008, A1011
Finish	Mill finish, pickled, oiled, galvanized, powder-coated
Standards	ISO 7805, DIN 24041, ASTM E2740, customer drawing

Common Hole Patterns and Open Area

Pattern	Hole / slot size	Pitch	Typical open area	Best for
Round staggered	1 – 10 mm	1.5 – 3.0 × D	23% – 50%	Filtration, screens, guards
Round straight	2 – 20 mm	2.0 – 4.0 × D	20% – 40%	Architectural, ceiling tiles
Square	3 × 3 – 20 × 20 mm	4 – 8 mm	25% – 45%	Sieves, machine guards
Slotted	0.5 × 5 – 5 × 50 mm	1.5 – 3.0 × W	15% – 40%	Self-cleaning screens, filters
Hexagonal	5 – 25 mm A/F	1.15 × A/F	65% – 70%	Acoustic panels, diffusers

Material and Finish Selection Guide

Application	Material	Finish	Notes
Industrial filtration	Q235, SPHC	Mill or pickled	Oil-free if for food contact
Architectural facade	S355, DC01	Powder-coated	RAL color matching available
Outdoor screening	Q235, S355	Hot-dip galvanized	Z275 coating for 15+ year life
Acoustic ceiling	DC01, A1008	Painted or plain	Hex pattern for high open area
Anti-slip platform	Q235, S275	Plain or HDG	Grip strut or raised dimple add-on

Manufacturing Standards and Quality Control

Incoming coil or plate is verified for thickness, flatness, and chemistry. Tooling is inspected before each production run for wear that could cause burr or taper. During punching, first-off and hourly samples are checked for hole diameter, pitch accuracy, burr height, and open area percentage. Burr is controlled to ≤ 0.1 × thickness for standard applications and ≤ 0.05 × thickness for fine filtration. Flatness is restored by roller leveling after perforation. For coated products, coating thickness and adhesion are tested per ASTM D3359 or EN ISO 2409. Dimensional reports include sheet size, hole count, pitch measurement, and open-area calculation.

Applications

• Air and liquid filtration screens in HVAC, water treatment, and oil systems
• Machine and conveyor guards in factories and warehouses
• Architectural sunshades, balustrades, and decorative panels
• Acoustic ceilings and wall absorbers in auditoriums and studios
• Grain dryers, seed screens, and agricultural processing equipment
• Anti-slip stair treads, platform decking, and catwalks

Packaging and Shipping

Sheets are stacked with interleaving paper or plastic film to prevent scratching, then banded with steel straps and edge-protected with cardboard or wood. Coils are eye-to-wall or eye-to-sky loaded depending on container type. Each package is labeled with material grade, thickness, pattern, open area, sheet count, and weight. For export, we apply rust-preventive oil and VCI wrapping for uncoated material, and padded corner protection for powder-coated or painted sheets to prevent chipping. Custom kit packing by project cut list is available.
